Reviews

Cables

Basic Link interconnect

This cable offers a warm midrange with natural bass and smooth, extended treble.
A great cable to mate with most popular electronics such as Rotel, NAD, Denon, Yamaha, Cambridge, and many others.

Hand crafted in Canada using quality materials:

- high purity solid copper center conductor
- 100% foil shield and 40% braided shield, connected at both ends
- Unity gold plated RCA connectors with a pure copper center conductor
- soldered using high content silver solder

Basic Link speaker cable

Unity' Basic Link speaker cable is hand crafted in Canada using quality materials such as stranded oxygen free high purity copper conductors , with an aggregate 13 gauge.
The twisted pair of conductors use a PE dielectric, and are then covered with an esthetically pleasing mesh sleeve that also prevents abrasion.
Connectors supplied are Unity gold BFA banana plugs which fit all modern posts, including those from Europe.

These cables are well suited to speakers from Paradigm, PSB, Energy, Athena, Totem, StudioLAB, Angstrom, Mirage, Axiom, Dahlquist, and many others.

Solid Link interconnect

This cable uses a twisted pair of 18awg high purity solid core conductors with a foil shield to reject noise.

Terminated with Unity's own RCA connector or Neutrik XLR's with high content lead-free SILVER solder.

Hand crafted in Canada using quality materials:

- high purity solid copper conductors in a twisted pair configuration
- shielded with Mylar foil to reject noise
- Neutrik XLR or Unity gold plated RCA connectors with a pure copper center conductor and Teflon insulation
- soldered using high content silver solder
- outer jacket protects the cable from abrasion, and makes it look great!

Solid Link speaker cable

Unity’s Solid Link speaker cable is hand crafter in Canada using quality materials such as solid high purity oxygen free high conductivity copper conductors, in a litz configuration.
Aggregate gauge is 13 awg for the positive leg, and 15 awg for the negative leg.
Each conductor is PVC insulated and then covered with a PVC jacket, topped off with an esthetically pleasing mesh sleeve that also prevents abrasion.

Connectors supplied are Unity gold BFA banana plugs which fit all modern posts, including those from Europe.

Speakers

Inner Spirit

A bookshelf speaker that is easily driven with as little as 3 watts. Perfect for single ended tube amplifiers. These can also be used with most solid state amplifiers with ease.
This crossover-less design gets the midrange right like no other speaker on the market. The imaging is rock solid, the speakers dissapear, leaving the performers in front of you.

Your spouse will be wearing a smile, as these are not the usual black boxes that are typically seen. Standard finish is a serene white (as shown), optional colours red, green, blue, yellow, etc. are limited only by your imagination.

WHAT COLOUR IS YOUR INNER SPIRIT?

Specifications:
Type: rear ported, single driver, bookshelf or stand mount
Cabinet: MDF construction
Finish: multiple coats of hand finished enamel and clear coat
Driver: Fostex 4.5 inch full range, shielded, modified for Unity Audio
Internal wiring: Unity Link series
Frequency response: 59Hz - 20kHz
Sensitivity: 93 dB
Impedance: 8 Ohm
Dimensions: 8.25W X 8.25D X 12.75H inches
Weight: 19 pounds/pair
Warranty: 10 years, limited

Customer comments/reviews:

"I have been listening to them all week-end on a Trends TA-10 amp and I am very impressed with the purity of the sound, the midrange are just fabulous." - F. Louvet, Paris,France

They really sound excellent. I'm quite impressed with the sound the full range driver delivers. The imaging was also quite impressive. They sounded way bigger than the cabinet or driver dimensions would have suggested. - Hula Pie/Canuck Audio Mart

http://www.canuckaudiomart.com/forum/viewtopic.php?t=5367

http://www.6moons.com/audioreviews/unityaudio/unity.html

http://www.canuckaudiomart.com/forum/viewtopic.php?t=3761

Spirit

Unity Audio's Spirit tube friendly loudspeaker. Can be driven with as little as 3 watts. Equally happy with SS power!
Features a 4.5 inch Fostex full range driver modified for Unity Audio.
This crossoverless design produces a beautifully detailed sonic presentation. The enclosure is a double bass reflex design, with rear.
Includes spikes. The ones pictured are finished in figured cherry, other finishes and colours available

Specifications
Type: Floorstanding with spikes
Cabinet: MDF construction
Finish: exotic veneer or colour enamel
Driver: Fostex 4.5 inch full range, shielded, modified for Unity Audio
Internal wiring: Unity Link series
Frequency response: 49Hz - 20kHz
Sensitivity 93dB
Impedance 8 Ohms
Dimensions (inches) 36H X 9W X 11D
Weight 100 pounds per pair
Warranty: 10 years

Whitewater

Features a single full range 6.5 inch driver, specially modified for Unity Audio.
Internally wired with Unity Link series speaker cable. Binding posts are high quality gold plated and can accept bananas, large spades, pins, or bare wire.
Can be placed on a bookshelf, or on a 24 inch high speaker stand.
These speakers sound wonderfully HUGE with great detail that only a full range driver can deliver.

Frequency response: 50 - 20,000 Hz
Sensitivity: 94dB
Warranty: 10 years
Dimensions: 9W X 10D X 15H (inches)
Weight: 35 pounds per pair
Finish: multiples coats of colour enamel, optional exotic veneer

We've found these sound best with single ended tube amps but can be used with SS gear with great results.

Customer comments/reviews:

"I highly recommend the Unitys... They will sing good with almost anything.
If you have a very good system, you will be surprised to see how far these speakers can go.
Very good sounding and fun to play speakers."
- deramg/Canuck Audio Mart

http://www.6moons.com/audioreviews/unityaudio/unity.html

Clearwater

2 way bookshelf speaker, uses a 5 inch wool fiber woofer with rubber surround and cast basket, and a 1 inch soft dome tweeter with a dedicated tear drop shaped chamber.
Front ported for easy placement. 5 way gold binding posts - no cheap plastic nuts! Internally wired with Unity Solid Link speaker cable.
Crossover is a first order/6dB using Mundorf caps and inductors, which give super fast transients, resulting in a VERY REVEALING presentation.
This speaker will sound as good as the electronics hooked up to it.

Frequency response 44Hz - 20kHz
Sensitivity 89 dB
Impedance 4 Ohms
Power handling 100 watts
Bass driver 5 inch woofer with rubber surround and cast basket
Tweeter 1 inch soft dome with tear drop chamber
Dimensions 7.75" W x 13" H x 9" D
Weight 30 pounds per pair

Coming soon
Eloquence
A series of components including a Tripath based power amplifier, speakers with ribbon tweeters,
digital and analog interconnect, speaker cable, and power cable.
